Application:
This automatic screen printing equipment is very suitable for automobile dashboard, membrane button, membrane circuits, transparent conductive film, solder paste, rigid PCB, electronic panels and so on..
Machine Features:
1.The printing pressure is uniform and adjustable, which can be adapted to the different needs of various inks.
2.The printing transmission mechanism is driven by a servo motor, the printing speed reaches about 500pcs/hour, CCD camera positioning through XYθ axises to rotate printing table, accuracy is +/-0.02mm.
3.Using PLC (programmable controller) control, touch screen setting servo drive, it's very convenient to operate.
4. Unique network version synchronization and off-grid mechanism to avoid the phenomenon of sticking to the network. Constant pressure control system to ensure the pressure balance of the squeegee and the uniform ink to ensure high printing quality.
5.Powerful suction motor, unique suction control, so that the substrate is firmly adsorbed and released in time.
6. The unique platform blowing and suction system and servo push scale block ensure accurate positioning in the XY direction.
7.Chinese and English HMI operation, reliable and durable, easy to adjust, accurate setting and complete functions.
Product Parameters:
| Model | VT6090P-1 |
| Printing size | 500x700mm |
| Printing table | 680*880mm |
| CCD alignment accuracy | 0.02mm |
| Printing accuracy | 0.05mm |
| Voltage | 380V |
| Power | 5KW |
| CCD center distance | 330mm |
Packing & Delivery:
1. All machines packed by polywood case;
2. Payment terms: 100% T/T(50% deposit to start production, balance 50% paid off before shipping);
3. Production leadtime: 25-35 days after receiving deposit;
4. Shipping port: shenzhen ports(yantian or pinghu port)
