Application:
Suitable for precise screen printing on Flexible Printed Circuit (FPC), capacity type touch panel, ITO conductive glass, ITO conductive film, blood sugar tester, EL panel, etc.
Characteristic :
High accuracy of vacuum table flatness, appropriate vacuum hole diameter can be made depending on substrate thickness, CCD visual system collaborates with three servo motors for auto substrate registering, printing head equips guide rail cylinders for equalized air pressure to be presented completely on printing pressureOptional cleaning roller can pick up dust or particles rapidly; anti-static bar can eliminate electrostatic on substrate for smooth printing; enclosure keeps printing section cleanThrough overall collocation to raise yield rate of efficient printing in massive production.
Features:
Upgraded Precision : three servo motors are equipped to control table X-Y-θ axis adjustments, by CCD visual system to judge stroke of table adjustment. CCD automatically calculates the spatial position of the material and the screen based on the mark point on the material, and instructs the motor to control the adjustment platform X-Y-θ axis to rotate and automatically position and print. CCD positioning accuracy is within 2µm and printing accuracy is within 5µm .
Uniform thickness of printed layer : guide rail cylinders are equipped for squeegee / flood coater to enhance precision and smoothness of up down motionLet equalized air pressure to be presented completely on substrate, and achieve very uniform thickness of printed layer.
Servo motor direct driven : low malfunction, solid printing torque, complete digital control, full stroke extreme stable speed motion.
Equalized pressure control : Adopted digital pressure equalizing system for squeegee / flood coaterAir pressure can be preset (3~62 kgf) through touch screen panel.
Safety Protection : error diagnosis in chain circuit, error displaying, single button to restore machine from safety loop, protective light barrier, E-stop switch, alarm light and so on for comprehensive safety protection.
