PCB Board Flatbed Screen Printing Machine

1. Stencil clamping frame adopts pneumatic automatic clamping design, easy to operate.
2. Safety pressure plate, photoelectric switch, emergency stop button, thorough safety protection.
3. Printing adopts Panasonic servo motor, with linear guide rail guidance, fast and smooth, accurate positioning.
4. The horizontal sliding seat adopts the overall aluminum agent type processing, running lightly without jitter.

Send Inquiry

Chat Now

Description

Aplication:

This machine is suitable for all flatbed material, such as acrylic sheet, PCB board, aluminium nameplate, metal plate, panels, membrane switch, mouse pad, label and stickers, leather, plastic, etc.

Product Parameters:

Model	VT4050
Maximum screen frame size	500*800mm
Printing table size	400*500mm
Maximum printing area	300*400mm
Printing speed	500-100 times/ hour
Air pressure	5-8kg/㎝²
Voltage	380V/50HZ
Power	3.2KW
Weight	540kg
Machine size	L1400×W1010×H1850mm

Machine Configuration:

Item	Brand	Origin
Reducer 80#	North	Taiwan
Air cylinder	Jingcheng	Taiwan
Linear guide rail	HIWIN	Taiwan
Timming belt	MEGDYNE	Italy
AC contactor	Zhengtai	China
