Features:
1.Operational Convenience: It is equipped with a visual touch screen that supports presetting multiple sets of processing parameters and one-click switching. New operators can take up their positions after simple training.
2.Operational Stability: The machine body adopts an integrated cast steel structure and is fitted with a shock-absorbing base. During high-speed operation, the amplitude is controlled within 0.2mm to ensure punching precision.
3.Easy Maintainability: Core components adopt a modular design and are equipped with a maintenance reminder function. Daily inspection and maintenance do not require professional personnel, which greatly reduces operation and maintenance costs.
Its Application Scope Also Covers Multiple Segmented Industries
In the electronics industry, it can complete precision micro-hole machining of flexible circuit boards.
In the advertising industry, it is suitable for irregular hole drilling of acrylic signboards.
In the new energy field, it can achieve precise punching of lithium battery tabs.
In the medical device industry, it can meet the sterile punching requirements of medical sheet materials, fully demonstrating the device's adaptability value and practical attributes across multiple fields.
| Model |
VTP15 |
| Max punching force | 700N |
| Material width | 0-520mm(can be customised) |
| CCD positioning accuracy | ±0.02mm |
| Pneumatic pressure | 0.4~0.8Mpa |
| Outline size | 1250*700*(770+260)mm |
