Application:
This machine is widely used in PET, PVC, PC, OPP, BOPP, membrane switches, signs, FPC flexible circuit boards, electronic labels, ITO conductive films, electric car and motorcycle car decals, electric heating films, IMD/IML mobile phone shells, 3M glue, Screen printing of roll materials such as laser trademarks, anti-counterfeit scratch cards, self-adhesive labels, and special inks and glues and other roll flexible material.
Features:
1. Adopts uniform speed function to ensure that the material stays in the oven at any position for the same time and rewinding speed.
2. The suction tension can be arbitrarily stepless adjustment, convenient to control the material tension, to ensure that the printing material does not stretch deformation.
3. Oven using 4 sides, 4 surface heat, makes the wind more smooth.
4. The oven with heat insulation cotton, circulation 10 layer, saves electricity and energy, more environmental.
5. The oven installed a device to assist feeding material, easy to use, improve the work efficiency.
Product Parameters:
| Model | KX500 |
| Oven size | L2450*W1250*H2100mm |
| Weight | 1000kg |
| Power | 15KW(Three-phase five-wire) |
| Voltage | 380V 50HZ |
| Rewinding inner diameter | 500mm |
| Oven temperature range(ºC) | Room temperature-200ºC |
| Feeding width | 52M |
