Application:
Adhesive products, backlight, dust-proof net, copper foil, aluminum foil, protective film, PE, PET, optical film, black and white glue, frame glue, single and double-sided tape, Mylar, foam and other materials.
Equipment features:
1. Adopt advanced computer digital drawing system, double servo drive, PLC program control, touch screen operation：
①High die-cut speed, high efficiency；
2. Whole machine design：
①The feed rack adopts a fine-tuning device to make adjustment more convenient and faster; ②The die-cutting part, material import and export and the feeding rack are all made of stainless steel, and the scale is corroded to make the material easier to adjust; ③The machine has high precision and noise The advantages of small size and fast speed; ④Servo main motor drive, more stable stamping and power saving.
3. Die-cutting part：
①Can be installed: engraving mold, wood mold, rubber mold, corrosion mold, hardware mold; ②It can easily realize multiple automatic punching, and the positioning accuracy is high; ③It can be punched or partially broken; ④It is equipped with mirror Light curtain safety protection device to ensure the safety of operators;
4. Automatic oil supply system to ensure the life and stability of the machine；
5. Can be used online with laminating machines, slicers and other equipment.
Machine parameters:
| Machine model | VT-350 |
| Template area | 350*305mm |
| Max material width | 360mm |
| Die-cut speed | 18000p/h |
| Adjustable stroke | ±3.5mm |
| Applicable knife mold | Wood mold,rubber plate mold,AB mold、engrave mold,hardware mold |
| Pulling accuracy | ±0.05mm |
| Power | 4.8KW |
| Voltage | 380V |
Machine weight | 1800kg |
| Machine size | L1950*W1300*H1800mm |
