Application
This automatic heavy hydraulic press is applied for large size flatbed products, such as, flexible printed circuits(FPC), membrane switches, membrane keypads, membrane circuits, graphic overlays, etc.
Video Case
Process Introduction
Load a roll--Pulling structure(pull material from point A to point B)--Platform suction--CCD register--Platform alignment--punching--Pulling structure(pull material from point B to point C)--Waste rewinding--Finished product transfer by conveyor belt--CCD detects defect product--Defect product is picked up to defect product box by defect product robot/good product is picked up to good product box by good product robot--Cycle production-- Replace the unloading box after it is full;
Technical Data
| Item | Parameters |
| Punching force | 60T |
| Material size | L：MAX: 1200mm MIN:300mm W: MAX：600mm MIN:120mm |
| Material | FPC |
| Max punching speed | 400P/H |
| CCD positioning accuracy | ±0.02mm |
| Punching accuracy | ±0.07mm |
| Power supply | 380V-60Hz, 10kW |
| Weight | About 3500KG |
